SEWER
Water receiverEZ-II Polygon waste water receiver
Specification
| A | L | L1 | Z | Z1 | E | E1 | H | H1 |
|---|---|---|---|---|---|---|---|---|
| 160 | 188 | 249 | 187.9 | 248.9 | 172 | 269.5 | 518.5 | 498 |
| DN | Inflow part | Outflow part | Z1 | Z2 | L | L1 | L2 | L3 |
|---|---|---|---|---|---|---|---|---|
| 300X150X100 | 100 | 150 | 188 | 172 | 384 | 210 | 283 | 125 |
SEWER
Water receiver| A | L | L1 | Z | Z1 | E | E1 | H | H1 |
|---|---|---|---|---|---|---|---|---|
| 160 | 188 | 249 | 187.9 | 248.9 | 172 | 269.5 | 518.5 | 498 |
| DN | Inflow part | Outflow part | Z1 | Z2 | L | L1 | L2 | L3 |
|---|---|---|---|---|---|---|---|---|
| 300X150X100 | 100 | 150 | 188 | 172 | 384 | 210 | 283 | 125 |
