BUILDING
General fittings [ Sextia ]Insert part
Specification
| DN | d (min) |
d1 | d2 | Tolerance of d1,d2 |
D | D1 (min) |
ℓ (min) |
ℓ1 |
|---|---|---|---|---|---|---|---|---|
| 50 | 54 | 61 | 61 | ±0.25 | 90 | 61 | 37 | 20 |
| 75 | 84 | 90 | 89 | ±0.30 | 125 | 90 | 62 | 24 |
| 100 | 108 | 115 | 114 | ±0.30 | 153 | 115 | 74 | 28 |
